GPU Architecture
GPU Model: NVIDIA GeForce RTX 3060 (GA106-300-A1)
CUDA Cores: 3,584
Architecture: NVIDIA Ampere
Ray Tracing Cores: 2nd Generation
Tensor Cores: 3rd Generation with DLSS support
Memory
Memory Size: 12 GB GDDR6
Memory Interface: 192-bit
Memory Speed: 15 Gbps
Memory Bandwidth: Approximately 360 GB/s
Display & Outputs
Max Digital Resolution: 7680 × 4320 (8K)
Outputs:
2 × HDMI 2.1
3 × DisplayPort 1.4a
Maximum Displays Supported: 4
HDCP Support: Version 2.3
Power & Connectivity
Interface: PCIe 4.0 x16
Power Connectors: 1 × 8-pin PCIe
Recommended PSU: 750W
Power Consumption (TDP): Approximately 170W
Cooling & Design
Cooling System: Triple Axial-tech fans with 2.7-slot design
Dual BIOS: Performance and Quiet modes
RGB Lighting: Addressable RGB with Aura Sync support
Backplate: Vented backplate for improved airflow
Dimensions
Length: 300 mm
Width: 134 mm
Height: 53.5 mm
Additional Features
Software: ASUS GPU Tweak II for performance tuning and monitoring
Accessories Included: ROG Velcro Hook & Loop, Collection card, Speedsetup manual
