TP-Link M7005 4G LTE Mobile Wi-Fi – Detailed Specifications
General
- Model: TP-Link M7005
- Device Type: Portable 4G LTE Mobile Wi-Fi (MiFi)
- SIM Type: Nano SIM
- Management: tpMiFi App (Android & iOS) and Web Interface
- Maximum Connected Devices: Up to 10 devices simultaneously
Mobile Network
- 4G LTE Download Speed: Up to 150 Mbps
- 4G LTE Upload Speed: Up to 50 Mbps
- 3G Fallback Support: Yes (HSPA+/HSPA/WCDMA)
LTE Bands
FDD-LTE
- B1 (2100 MHz)
- B3 (1800 MHz)
- B5 (850 MHz)
- B7 (2600 MHz)
- B8 (900 MHz)
- B20 (800 MHz)
- B28 (700 MHz)
TDD-LTE
- B38 (2600 MHz)
- B40 (2300 MHz)
- B41 (2500 MHz)
Wi-Fi Specifications
- Wi-Fi Standard: IEEE 802.11 b/g/n/ax (Wi-Fi 6)
- Frequency Band: 2.4 GHz
- Wireless Speed: Up to 287 Mbps
- Wireless Security:
- WPA-PSK
- WPA2-PSK
- WPA3-SAE
- MAC Filtering
- SSID Broadcast Control
Battery
- Battery Capacity: 2400mAh
- Battery Life: Up to 12 hours of continuous use
- Charging Port: USB Type-C
- Power Input: 5V/1A
Hardware
- Dimensions: 114 × 70 × 23.85 mm
- Weight: Approximately 118g
- Antennas: Internal LTE/Wi-Fi Antennas
- Buttons:
- Power
- Reset
- LED Indicators:
- Wi-Fi Status
- Internet Status
- Power/Battery Status
Software Features
- Device Management via tpMiFi App
- Data Usage Monitoring
- Device Access Control
- DHCP Server & Client
- SMS Management
- Wi-Fi Security Management
- Data Limits & Alerts
Package Contents
- TP-Link M7005 Mobile Wi-Fi
- USB-C Charging Cable
- Quick Installation Guide
