1. Main specifications
Feature | Specification |
|---|---|
Brand | Lenovo |
Product family | ThinkCentre neo |
Model | neo 50a 24 Gen 5 |
Part number | 12SC00BBUM |
Computer type | All-in-One desktop |
Processor | Intel Core i5-13420H |
Processor generation | 13th Gen Intel Core |
CPU cores | 8 (4 performance + 4 efficiency) |
CPU threads | 12 |
Maximum turbo frequency | Up to 4.6 GHz |
Processor cache | 12MB Intel Smart Cache |
RAM | 8GB DDR5-5200 |
Memory configuration | 1 × 8GB SODIMM |
Maximum supported RAM | Up to 32GB DDR5-5200 |
Storage | 512GB M.2 2280 PCIe 4.0 NVMe SSD |
Graphics | Integrated Intel UHD Graphics |
Display | 23.8-inch Full HD IPS |
Resolution | 1920 × 1080 |
Touchscreen | Configuration-dependent; verify this part number |
Operating system | Depends on the supplied regional configuration |
Wireless | Wi-Fi 6 |
Bluetooth | Bluetooth 5.2 on the matching listed configuration |
Wired network | Gigabit Ethernet |
Colour | Typically Luna Grey |
Warranty | Commonly listed as 1 year; confirm locally |
2. Processor and performance
Intel Core i5-13420H
Processor cores
8
4 performance + 4 efficiency
Threads
12
Parallel processing
Maximum turbo
4.6 GHz
Cache
12MB
The i5-13420H is an H-series processor designed for relatively strong performance. Its combination of performance and efficiency cores helps balance demanding tasks with background processes.
It is suitable for:
Office applications, accounting and business management software.
Heavy web browsing and multitasking.
Video conferencing and remote work.
Programming and general software development.
Everyday photo editing and light creative applications.
The integrated graphics are not intended to replace a dedicated GPU for high-end gaming, advanced 3D rendering or GPU-intensive video production.
3. Memory and storage
RAM
Installed memory: 8GB DDR5-5200.
Memory slots: Two SODIMM slots.
Maximum supported capacity: Up to 32GB DDR5-5200.
Dual-channel memory support: Yes.
Recommendation: Upgrade to 16GB for heavier multitasking, large spreadsheets and more demanding business applications. The exact upgrade configuration should be checked against Lenovo’s supported memory options.
SSD storage
Capacity: 512GB.
Form factor: M.2 2280.
Interface: PCIe 4.0 ×4 NVMe.
Maximum listed storage support: One SSD up to 1TB.
Optical drive: None.
Memory card reader: None.
The NVMe SSD offers fast boot times and responsive application loading.
4. Display specifications
Feature | Specification |
|---|---|
Screen size | 23.8 inches (approximately 60.5 cm) |
Resolution | Full HD, 1920 × 1080 |
Panel technology | IPS |
Brightness | 250 nits |
Colour coverage | 99% sRGB |
Aspect ratio | 16:9 |
Contrast ratio | 1300:1 |
Refresh rate | Up to 100Hz |
Response time | 14ms |
Surface | Anti-glare |
Eye-care features | Low blue light and flicker-free design |
Touchscreen | Available on selected configurations |
The 100Hz refresh rate can make scrolling and everyday motion appear smoother than on a standard 60Hz screen. However, confirm whether P/N 12SC00BBUM is the touch or non-touch version before purchasing. Lenovo offers both configurations for this model family.
5. Graphics
Feature | Specification |
|---|---|
Graphics processor | Intel UHD Graphics |
Type | Integrated |
Video memory | Shared system memory |
DirectX support | DirectX 12.1 |
Maximum listed HDMI resolution | Up to 4096 × 2160 at 60Hz |
Integrated graphics are appropriate for everyday business work, video playback, presentations and light photo editing. They are not a substitute for a dedicated graphics card in demanding gaming or professional 3D workloads.
6. Ports and connectivity
Port | Location | Specification |
|---|---|---|
USB-C | Left side | USB 10Gbps; data transfer and 15W charging |
Headphone/microphone combo | Left side | 3.5mm audio jack |
USB-A | Rear | 1 × USB 10Gbps |
USB-A | Rear | 2 × USB 2.0 |
HDMI input | Rear | HDMI 1.4 |
HDMI output | Rear | HDMI 2.1 TMDS |
Ethernet | Rear | RJ-45 Gigabit Ethernet |
Power input | Rear | External power adapter |
The two HDMI connections serve different purposes:
HDMI-in: Allows a compatible laptop or other video source to use the All-in-One’s screen.
HDMI-out: Connects the Lenovo to an external monitor.
This is useful for presentations and for extending your desktop to a second screen.
7. Camera, speakers and audio
Feature | Specification |
|---|---|
Camera | 5MP |
Camera option | 5MP infrared camera on selected configurations |
Privacy | Physical camera shutter |
Microphones | Dual-microphone array |
Speakers | Stereo, 2 × 3W |
Audio codec | Realtek ALC233-CG |
Audio branding | Audio by HARMAN |
The 5MP camera offers higher nominal resolution than a typical 720p webcam. An infrared camera, where fitted, can support compatible facial-recognition features. Confirm the precise camera option for the supplied part number.
8. Operating system and accessories
Item | Details |
|---|---|
Operating system options for the model family | Windows 11 Home, Windows 11 Pro, Windows 11 Home Single Language, Ubuntu or no preinstalled OS |
Keyboard | Lenovo Calliope wired USB or optional wireless keyboard |
Mouse | Lenovo Calliope wired USB or optional wireless mouse |
Power supply | 90W or 135W adapter, depending on configuration |
Security | Firmware TPM 2.0 |
Physical security | Kensington Security Slot on applicable units |
The exact operating system, keyboard layout and adapter supplied with P/N 12SC00BBUM must be confirmed with the seller. If it comes without an operating system, budget separately for installation and any required licence.
9. Physical dimensions and design
Feature | Specification |
|---|---|
Width | 540mm |
Depth | 192mm |
Height | 431mm |
Weight | Approximately 6.0kg |
Colour | Luna Grey |
Form factor | 23.8-inch All-in-One |
Stand adjustment | Approximately −5° to +15° tilt |
VESA mounting | Not listed as supported in the cited standard configuration |
